Monitor Audio IA750-2 - 2 Channel Power Amplifier
Monitor Audio IA750-2 - 2 Channel Power Amplifier
Couldn't load pickup availability
The IA750-2 high-power amplifier with advanced DSP is easy to set up and control. It delivers two channels of 750 W of power from a robust 2U full width design.
The IA750-2 is perfect for larger installations and outdoor systems. It offers two channels of 750 W each, plus it is ideal for subwoofer installations thanks to its power sharing technology where it can deliver 1500 W to Monitor Audio’s Cinergy Sub15. A 2U full width high power amplifier, it features full DSP matrix configuration using a web app configurator and is a breeze to install and use.
Features
- 2 x 750 W
- Fully customizable DSP amplifier with web configurator
- Full width 2U rack format
- High performance Class D amplifiers ensure excellent power and sound delivery
- Power Sharing technology
- Supports 70/100V line level speakers
- 5 Year Warranty
SPECIFICATIONS
|
Channels |
2 |
|
Output Power @ 2 Ohms |
2 x 750W SE |
|
Output Power @ 4 Ohm |
2 x 750W SE, 1 x 1500W BTL |
|
Output Power @ 8 Ohm |
2 x 400W SE, 1 x 1500W BTL |
|
Output Power @ 70V |
1 x 1200W BTL |
|
Output Power @ 100V |
1 x 1500 W BTL |
|
Maximum Total Output Power, all channels driven |
1500 W |
|
Power Consumption |
350 W |
|
Thermal Output |
1200 BTU |
|
Polarity (Default) |
Non-inverting |
|
Output Voltage |
80Vp / 160Vpp (SE unloaded), 160Vp / 320Vpp (BTL unloaded) |
|
Signal to Noise Ratio |
>108dB (A-weighted, 20Hz – 20kHz, 8 Ohm load) |
|
THD+N (typical) |
<0.05% (20 Hz – 20 kHz, 8 Ohm load, 3db below rated power) |
|
Frequency Response |
+0/-0.25dB 20Hz – 20kHz (8 Ohm load, 3dB below rated power |
|
Protection Circuits |
Short circuit -, DC, Undervoltage -, Temperature – and Overload protection |
|
Power Supply |
Switch mode power supply with Power Factor Correction (PFC) and standby converter |
|
Operating Voltage/Frequency |
Universal Mains, 100 V – 240 V, 50 Hz – 60 Hz |
|
Standby Consumption |
<0.5W |
|
Accessories |
Rack mount kit (pre-installed) |
|
Power Ratings |
1% THD @ 120Vac and 230Vac |
|
Cabinet Finish |
Black Anodised |
|
Dimensions |
88 x 440 x 329 mm (36/16 x 175/16 x 1215/16”) |
