The Vestra W12 Subwoofer is built to deliver uncompromising bass performance, perfect for any high-fidelity setup as a standalone item or in multiples for the ultimate fully immersive AV experience.
Features at a glance:
- High linear-excursion C-CAM (Ceramic Coated aluminium Magnesium) driver
- Triple suspension driver
- 500-Watt Class-D Amplifier
- Sealed-Enclosure
- Three EQ pre-set modes
- Stereo unbalanced RCA inputs
- LFE unbalanced RCA inputs
- 12 Volt trigger
- 3.5mm mono jack
Performance-driven bass for every listener.
The Vestra W12 subwoofer delivers a potent combination of power, precision, and seamless design. Utilising Clever DSP (Digital Signal Processing) enhances customisation, allowing you to fine-tune the bass response to your space.
The Vestra W12’s sealed-enclosure design houses a 12-inch C-CAM (Ceramic-Coated Aluminium Magnesium) high linear-excursion driver featuring triple-layer suspension for greater control and ensuring precise, powerful bass with minimal distortion. Supported by a robust 500-watt Class-D amplifier and a rigid, acoustically optimised enclosure, the W12 delivers deep, impactful lows that remain clear and controlled at all listening levels.
Subwoofers and Their Ideal Placement
Forget simply finding a spot that fits-proper subwoofer placement is a crucial element in the art and science of audio, requiring a touch of knowledge and a willingness to experiment.
|
System Format |
Active |
|
Frequency Response (In-room, -6dB) |
17 — 200 Hz |
|
Maximum Usable SPL - Peak (CTA 2010-B, Z-weighted, half-space) |
115 dB |
|
Amplifier Output Instantaneous (RMS) |
500 W |
|
Amplifier Classification |
High-Efficiency Class-D |
|
Bass Alignment |
Sealed |
|
Low Pass Filter Frequency (-6dB) |
32 — 200 Hz |
|
Inputs |
Stereo Unbalanced RCA LFE Unbalanced RCA 12 V Trigger 3.5 mm mono jack |
|
Input Impedance |
47 kOhms |
|
Phase Control |
0° & 180° Toggle Switch |
|
Equalisation DSP |
3 pre-set modes: Impact, Movie, Music |
|
Auto Music Sensing |
Auto On: Line Level >3 mV | Auto Standby after 20 mins |
|
Mains Input Voltage |
Universal Mains, 85 - 265 VAC, 50 - 60 Hz |
|
Power Consumption (1/8th Maximum Output) |
120 W |
|
Drive Unit Complement |
1x 12" (305 mm) High Linear-Excursion Triple Suspension Driver |
|
External Dimensions with all accessories fitted (H x W x D) |
385 x 371 x 401 mm (151/8 x 149/16 x 1513/16") |
|
Weight |
18.3 kg |
|
Grille |
Cloth covered |
