Velodyne Acoustics Deep Blue 8 - Active Subwoofer
Velodyne Acoustics Deep Blue 8 - Active Subwoofer
Pressurized, precise low frequency for every living ambiance
The Deep Blue Series combines all the benefits of Velodyne Acoustics subwoofers in a living room-friendly format. The frequency response of the front-firing drivers, designed from the ground up, extends deep into the frequency basement for impressive home theater experiences.
The Features
- Quad voice coil provides high efficiency, fast rise times and pulse fidelity with double ferrite magnets
- Enclosed cabinet made of solid MDF material prevents distortion and vibration
- With adjustable level, crossover frequency and phase, the Deep Blue subwoofers can be flexibly adapted to the listening room and existing equipment
- For connectivity, RCA input jacks are provided for the left and right channels, as well as a dedicated subwoofer input with loop-through capability
The matching subwoofer for every setup
With drivers ranging from 8 to 15 inches, the Deep Blue series offers the right subwoofer for every set-up.
SPECIFICATIONS
Driver |
8″ forward firing |
Amplifier Class AB |
800 watts dynamic, 300 watts RMS power |
Frequency Response: Overall Frequency Response: (± 3 dB) |
18 – 300 Hz 32 – 180 Hz |
Low Pass Crossover |
50 Hz to 180 Hz (12 dB/Octave) |
Phase |
0 to 180 degrees |
Cabinet Design |
MDF Closed Box with 52mm / 2” front Baffle |
Magnet Structure |
Dual ferrite magnet motor |
Woofer |
8” high excursion double vented basket driver with PP inforced Membrane |
Voice Coil |
Four Layer 2″ / 52mm Voicecoil |
Input |
GoldPlated Line in Stereo RCA, LFE in, Nickel Plated Highlevel |
Output |
Gold plated LFE /RCA |
Power Selector |
Off / Auto / On |
Dimensions (W/H/D) (includes feet and connectors) |
26 x 28 x 29 cm |
Weight (approx) |
9kg |
Shipping Weight (approx) |
10kg |
